Protective tool for large applications
Detek large buffers are often used in large applications. The hardened and reinforced parts and high-energy absorption design can effectively protect machinery and equipment from the impact of heavy loads, providing comprehensive five-star safety protection for machinery and equipment! At the same time, the delicate design of the adjustment knob allows the adjustment of the large buffer without disassembly under actual use conditions, which is very convenient and practical.
● DTD is an adjustable model. You can adjust the damping force according to the impact speed. The adjustment knob can be rotated 180 °, the scale ranges from 0 to 8, and the buffer is from soft to hard. You can adjust it to the best possible effect.
● The threaded cylinder ensures reliable and accurate installation and fixation, and the enlarged contact area promotes the release of thermal energy to the air.
● The piston rod is made of reinforced stainless steel, the guide bearing is made of high-strength wear-resistant materials, and the sealing system is made of special materials, which can effectively ensure the long service life of the buffer.
● The use of polyurethane silencer caps can replace the use of boundary sleeves and effectively reduce impact noise.
● Impact speed range
Standard model: 0.3 ~ 5.0 m/s
Low speed model: 0.08 ~ 1.3 m/s
● Temperature range
Standard model:-10 ~ 80 ℃
Optional range:-40 ~ 120 ℃ (special hydraulic oil and oil seal)
SPECIFICATIONS
Energy absorption 250 nm/cycle-18,500 nm/cycle
Stroke 25 mm-250 mm
Impact velocity range 0.08 m/s to 5.0 m/s. For speeds outside the range, please contact Damptac.
Working environment temperature-10 °C to 80 °C. For temperatures outside the range, please contact Damptac.
Can be installed in any position.
Integrated end stop.
Material of outer cylinder body: nitriding hardened steel, piston rod: hard coated hardened steel, piston rod cap: reinforced steel with anti-corrosion treatment on the outer surface; Return spring: special spring steel; Accessories: Nickel plated or QPQ
Damping medium: special hydraulic oil for damping deceleration
Note
Avoid the impact of external adverse factors on the buffer.
1. The buffer is filled with hydraulic oil. Do not use it near an open flame. It is strictly forbidden to burn the buffer.
2. Make sure the buffer is used within the operating temperature (-10 ℃-80 ℃). If you need to use it at a special temperature, please contact us.
3. Prohibit contact with corrosive substances such as acids, solvents, emulsified cutting oil, etc., and avoid contact with dust, steam, etc.
4. It is forbidden to spray paint on the outer cylinder of the buffer, otherwise it will affect the heat dissipation.
It is forbidden to paint or mark the piston rod to prevent the leakage of hydraulic oil and shorten the life of the buffer.
Automotive industry
Non-standardized automation industry
Laser cutting industry
Wood processing industry
Steel industry, etc.
Testing equipment, etc.
Paper making equipment etc.
